Magnetic SwitchesCharacteristicsDouble Break MechanismINO+INC Force Break snap actionRated Voltage / Current10(4)A, 125, 250VAC / 6(2)A, 380VAC For inductance Load, Cos=0.4Contact Resistance25m max. (initial value) Dielectric Strength1000VAC, 50/60 Hz for 1 minute between terminals of the same polarity1500VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts1500VAC, 50/60 Hz for 1 minute between each terminal and groundElectrical Life500,000 at 10A 250VAC ResistiveMechanical Life10, 000, 000 operations min. (under rated conditions)Operating Speed5mm/s to 0.5m/sDegree of ProtectionIP66Ambient Temperature RisedMax 30over ambient temperature at rated voltage/current Operating Temperature-5~+65(with no icing)Storage Temperature-5~+65(with no icing)Ambient Operating Humdity95% RH Max.Shock Resistance Malfunction: 300m/s2 min.Vibration FrequencyMalfunction: 10 to 55Hz, 1.5mm double amplitudeTerminal Screw Torsional Force6-8 kgf-cmOther Screw Torsional ForceCover 12-14 kgf-cm/Head 8-9 kgf-cm/Mounting 50-60 kgf/cmBare Wire Diameter2 MaxCable Diameter12 Max(IP 65 if use cable 8-9)
